HEIGH10 – 10 INCH TOUCHSCREEN
Featuring a high-resolution, 10-inch digital touchscreen with 16.7 million colours for a full visual experience, the HEIGH10® is designed to enhance screen size and infotainment features for drivers.
The HEIGH10 features Anti-Glare and Anti-Reflection technology for the best in car visibility. Personalise your display with customisable RGB illumination to match factory illumination, or create your own.
APPLICATION
VW Tiguan 5N 2007 2015
VW Amarok 2016 2021
VW Crafter SY/SZ 2017 2021
VW Caddy 2K/KN 2015 2020
VW Beetle 5C1 2015 2019
VW Jetta 5C6 2011 2018
VW Transporter T6 2015 2019
VW Scirocco MK3 2015 2017
VW Grand California SY/SZ 2017 2019
VW Sharan 7N 2015 2021
Applications above that work on the MIB-PQ platform
INTEGRATION
• For bespoke installation into the vehicle, the dash kit and mounting included provide a factory look and feel when the HEIGH10 display is installed.
• The interface also provides more control over your Volkswagen infotainment installation with camera triggers and steering wheel controls.
RETAINS
• Steering wheel control functionality
• Phone button compatibility
• Outputs for speed pulse, reverse gear and park brake
• Factory camera feed (if applicable)
KEY FEATURES
YOUR MEDIA, YOUR WAY
Gain total access to your smartphone’s music and navigation capabilities.
• Apple CarPlay®
• Google Android Auto™
• DAB+ Digital Radio
• AM/FM radio
• 2 USB rear inputs, 1.5-Amp output
• Hands-free Bluetooth® 4.2
• A2DP with aptX™ (for hands-free calling and music streaming)
ADVANCED SOUND
HEIGH10’s sonic capabilities allow for a versatile and more detailed sound experience.
• Built-in amplifier (16W RMS x 4)
• 4V, 6ch RCA audio outputs with subwoofer control
• Toslink (optical) digital audio output
• 15-band adjustable graphic EQ
• 3 user EQ presets for each audio source
• Built-in crossover with High Pass Filter (HPF) and Low Pass Filter (LPF)
A SAFER RIDE
HEIGH10 4 AHD camera inputs help reduce risk and increase safety.
• 4 independent AHD camera inputs and triggers
• Onscreen camera input switching
• Customisable camera settings menu
• Rear camera selectable audio input for commercial and motorhome/campervan applications
INCLUDED
• HEIGH10 10-inch touchscreen display/infotainment system
• Vehicle-specific radio mounting dash kit
• Complete the vehicle integration module
• Vehicle & radio specific plug-and-play harnessing
• AM/FM antenna adapter
• USB retention cable
• Stereo connection lead
